(Model No.: Spectra AA 220 FS; Make: M/s Varian, Netherland)
Use to determine metal ion concentration using flame mode. Uses air-acetylene or nitrous oxide- acetylene burner. Equipped with vapor generation accessory and electro thermal controller for flameless hydride vapor analysis.
(Model No.: DL-50; Make: M/s Mettler Toledo, Switzerland)
Concentration determination with highest precision and productivity.
(Model No.: Tristar II; Make: M/s Micromeritics, U.S.A.)
For measuring the surface area and pore size distribution measurement at liquid nitrogen temperature. Important instrument in particle characterization.
(Model No.: Chemisorb 2720; Make: M/s Micromeritics , USA)
Use to measure the percent dispersion, active metal area, Crystallite & quantify acid or base site using pulse chemisorb.
(Model No.: Delsa Nano C; Make: M/s Beckman Coulter, Swtizerland)
Used to measure to Zeta Potential/ Submicron size analysis (0.6 nm to 7.0 Micron) with forward 15 Deg & backscatter 165 Deg.
(Model No.: DSC 1; Make: M/s Mettler Toledo, Switzerland)
Differential scanning calorimetry can be used to measure a number of characteristic properties of a sample. Using this technique it is possible to observe fusion and crystallization events as well as glass transition temperatures TG
(Model No.: IRAffinity-1; Make: M/s Shimadzu, Japan)
FTIR can be used for identification of functional group in raw material, polymeric films & Qualitative analysis. Use for powdered & liquid samples
(Model No.: CP-3800; Make: M/s Varian, Netherland)
For typical gas chromatography applications with provision for gas as well as liquid injection of samples. Equipped with three detectors viz. TCD (Thermal conductivity detector), ECD (electron capture detector) and FID (Flame ionization detector).
[Not Working]
(Model No.: 450-GC, 240-MS; Make: M/s Varian, Netherland)
Gas-liquid chromatography and mass spectrometry to identify different substances within a test sample. Applications of GC-MS include drug detection, fire investigation, explosives investigation, and identification of unknown samples.
(Model No.: Prominence HPLC System; Make: M/s Shimadzu, Singapore)
HPLC system for chromatographic separations. Equipped UV-Visible detector
(Model No.: Physica MCR 301, Make: Anton Paar, Austria)
Rheological measurements of interfacial films at gas/liquid and liquid/liquid interfaces.
(Model No.: Master sizer 2000; Make: M/s Malvern, UK)
Measures particle size distribution of suitably dispersed field of particles in the range 0.02 to 2000 micron. Provision for both dry (using air as dispersing media) and wet (using suitable dispersant) Dispersion available.
(Model No.: AMP 60 K-A-1; Make: Porous Material Inc., USA) Used to measure the porosity of a material by applying controlled pressure to a sample immersed in mercury.
(Model No.: Zeiss Axio Scope.A1, Make: Carl Zeiss Microscopy GmbH Germany)
Axio Scope.A1 are universal microscopes designed especially for applications in biological and medical fields and for material studies. Microscope is equipped with Reflected Light / Transmitted Light with Combination of HAL 100.
(Model No.: 908010, Make: CEM, U.S.A.)
Microwave Reactor provides an economical, robust platform for heating sealed pressure vessels with the power of microwave energy. Access temperatures and pressures up to 300 °C and 300 psi for the highest purity synthetic results.
(Model No.: Elix-3, Milli-Q; Make: M/s Millipore, USA)
Used for synthesis of de-ionized water applying RO and EDI technology. Synthesizing grade-1 water with resistivity -18.2 megaohms.cm, TOC <10ppb and particle <1 (0.22micorns per ml) indispensable for various experimental, reaction and analytical purposes
(Model No.: SITE 100; Make: M/s KRUSS gmbH, Germany)
Used to Measure the interfacial tension between two liquids & analyzing video image of a drop in a Rotating capillary upto 10-6 mN/m.
(Model No.: DY300; Make: M/s Kwoya, Japan)
Instrument dedicated to the study of sruface tension & interfacial tenaion Using ring & plate method.
(Model No.: TG 209 F1 Libra; Make: M/s Netzsch, Germany)
For differential thermo gravimetric studies, SDTA analyses under defined atmosphere (inert or reactive). With temperature programming up to 40 segment runs, furnace temperature up to 11000C and measurement precision up to 1 microgram.
| Components | |
| Two Cameras | : VEO 640 camera, 4MP, 1450 fps |
| Lasers | : Dual Power 30-1000 laser 2x30 mJ, 1000 Hz 527nm |
| Synchronizer | : Dantec dynamics |
| Software | : Dynamic studio |
| Measurement Steps | |
| 1. | Laser light sheet generation |
| 2. | Illumination of targeted area |
| 3. | Calibration of 2 cameras |
| 4. | Image recording and pre-processing |
| 5. | 2-D PIV calculation |
| 6. | Stereo PIV reconstruction from 2-D PIV |
| 7. | Data presentation and statistics |
Two cameras are employed to view the flow field from two viewing directions. Focusing an off-axis camera requires tilting of the camera sensor (Scheimpflug condition). Laser is used to generate light sheet to illuminate tracer particle inside flow. Each camera measures particle displacement normal to its viewing direction. Two projections of velocity (Δu, Δv) are obtained, one from each camera. All three components of velocity (Δu, Δv, Δw) vector can be reconstructed.
(Model No.: Aurora 1030 C; Make: M/s O.I. Analytical, USA)
TOC analyzer is totally automatic system for analyzing aqueous samples for Total Organic Carbon (TOC) and Total Inorganic Carbon (TIC). Using heated per-sulfate oxidation technology, samples containing 2 ppb to 30,000 ppm of organic carbonate analyzed.
(Model No.: Lambda 35; Make: M/s PerkinElmer, Switzerland)
Use to determine the absorption/ transmission spectra of the analyte. Different measurement methods like concentration, wave program and time drive method available. Typical application includes concentration measurement.
(Model No.: UV-2600, Make: Shimadzu, Singapore)
UV-2600 can be used for measurement of solar cell Anti-reflective films and polycrystalline silicon wafers.
(Model No.: Nanofilm_ep3sw, Make: Accurion GmbH, Germany)
To measure optical constant, thickness and refractive index of thin film. Also equipped with Langmuir-Blodgett troughs to prepare more layer films.
(Model No.: 450-GC, Make: Bruker, Germany)
For typical gas chromatography applications. Equipped with three detectors viz. TCD (thermal conductivity detector), Pulse Flame photometric Detector) and FID (Flame ionization detector).
(Model No.: TGA HP/1- HIGH PRESSURE; Make: M/s LINSESIS MESSGERAETE, GmbH)
The system can be used to determine simultaneous changes of mass (TG) and caloric reactions (HDSC) under defined atmosphere and high pressure (up to 100 bar) in the temperature range upto 1100°C.
(Model No.: D8 Advance, Make: Bruker, Netherlands)
Powder X-ray diffraction application used for structure determination, crystallinity and phase identification.
