This project is an initiative of Ministry of Human Resource Department under National Mission on Education through ICT. These experiments and labs will be hosted for open access through the main project website
Digital VLSI Design Virtual lab
To plot the (i) output characteristics & (ii) transfer characteristics of an n-channel and p-channel MOSFET.
To design and plot the static (VTC) and dynamic characteristics of a digital CMOS inverter.
To design and plot the output characteristics of a 3-inverter ring oscillator.
To design and plot the dynamic characteristics of 2-input NAND, NOR, XOR and XNOR logic gates using CMOS technology.
To design and plot the characteristics of a 4x1 digital multiplexer using pass transistor logic.
To design and plot the characteristics of a positive and negative latch based on multiplexers.
To design and plot the characteristics of a master-slave positive and negative edge triggered registers based on multiplexers.
