Equipped with advanced equipments for manufacturing including micro-fabrication facility using CO2 Laser cutting technology.
Lab Equipments
(Click on equipment for more information)
Coordinate Measuring Machine
Make: Accurate Spectra, Model: Spectra, Accuracy: 0.5 micron
Description:
To measure angle between two planes, linear distances etc., upto substantial precision and accuracy levels.
Coordinate Measuring Machine
3D Laser Scanner
Make: Roland DG Corp., Model: LPX 250
Description:
Used to scan 3D components and hence it may prove to be a resourceful apparatus for reverse-engineering/rapid-prototyping applications.
3D Laser Scanner
HSTP Injection Moulding machine with accessories
Make: Tex air
Description:
Used for large-scale fabrication of plastic components
HSTP Injection Moulding machine with accessories
Vacuum Coating Unit
Make: Vacuum Techniques Pvt. Ltd.
Description:
Used for specimen-coating with aluminium, silver etc.
Vacuum Coating Unit
2.5 kW CO2 Laser Cutting Machine
Make: LVD, Model: Orion 3015
Description:
Used for laser cutting, laser forming and laser welding
2.5 kW CO2 Laser Cutting Machine
3-axis CNC Milling Machine (10000 RPM)
Make: Precision Machine Kraft, Model: MC-3/400
Description:
Used for precision milling, drilling, turning etc.
3-axis CNC Milling Machine (10000 RPM)
Plastic Compression Moulding Machine (Hot Press)
Make: Sanmya, Model: HYPR-25T
Description:
Used for moulding complex, high-strength fibreglass reinforcements. Advanced composite thermoplastics can also be compression molded with unidirectional tapes, woven fabrics, randomly oriented fiber mat or chopped strand.
Tube furnace is used for a broad range of thermal processes, including: inorganic and organic purification; accelerated aging; annealing; coating; drying; and much more
Tube Electric Furnace
Twin Screw Extruder (Co-Rotating)
Make: High Torque ZV20
Description:
Twin screw extruder is used in many branches of industry for producing, preparing and/or processing highly viscous materials. They find a wide variety of applications especially in the plastics, rubber and food industries.
Twin Screw Extruder (Co-Rotating)
High Precision Non-Contact Computerised Surface Profilometer
Make: Taylor Hobson, Model: Talysurf CCI lite, Resolution: 1 Mega Pixel
Description:
Used for seeing surface topography and measuring surface roughness of components.
High Precision Non-Contact Computerised Surface Profilometer
Profile projector is widely used for measuring the dimensions and geometry of the part against prescribed limits. It is a useful item in small parts for the quality control inspection.
Vertical Profile Projector
Infra-Red Camera (Thermal imaging Camera)
Make: Infra Tec, Model: Vario CAM hr head 480 SL Max Temperature: 2000 Deg Celsius
Description:
Enhance the visual clarity of small items on the ground. Assess the extent of environmental damages without risking human lives. Monitor large geologic properties for changes.
Infra-Red Camera (Thermal imaging Camera)
Surface Roughness Tester (Talysurf)
Make: Mitutoyo, Model: SJ 401
Description:
Used for measuring surface roughness.
Surface Roughness Tester (Talysurf)
Surface Plate
Make: MMT/ Luthra, Model: IS-7327-2003-7micron
Description:
A surface plate is a solid, flat plate used as the main horizontal reference plane for precision inspection, marking out (layout), and tooling setup.
Surface Plate
Metrology Kit
Description:
Apparatus such as Slip Gauge, Micrometer, Sine Bar, Height Gauge, Depth Gauge, Thread Gauge, Bevel protractor, Combination Set, Filler Gauge, Radius Gauge etc.
Metrology Kit
Data Logger (Acquisition) Unit with 20 Channel Multiplexure
Make: Agilent/Keysight, Model: 34972A LXI
Description: None
Data Logger (Acquisition) Unit with 20 Channel Multiplexure
