Now a days experimentalists find interest in holographic optical tweezers where the laser beam used for trapping is holographically designed. Using holographic means one can implement several high quality optical traps to efficiently manipulate microscopic particles suspended in liquid medium. A realtime user reconfigurable hologram for such a purpose can be implemented using liquid crystal spatial light modulator (LCSLM).
In our laboratory we have realized a holographic optical tweezer using an LCSLM based arrangement. Our experimental setup uses an Olympus inverted microscope with 100x oil immersion objective lens of numerical aperture 1.4 to focus the holographically designed beam. We have observed the trapping of polystyrene beads of size 1 μm in the water using light from a DPSS laser of power 1.15W emitting at 532nm. The movie in Fig.1 shows our holographic optical tweezer in action. As seen when the trap is switched on it creates a strong gradient force and the beads near the focus get accumulated at the trap, indicated by the red circle. We then holographically move the trap from left to right, then from right to left and finally downwards.
|
|
